Help needed xpma color changing wave (rainbow)

Hi everyone, I could use a little help on this. I have tweaked things a little bit in the code, but can't for the life of me figure out how to adjust the slope or figure out how to buffer so that the yellow will stay yellow a little longer. I am trading 5 second charts using flexichart, and would like the wave to turn yellow as trend is running out of fuel and while in consolidation. I have this set up to lwma currently. Additionally, the colors are backwards red up and green down and I haven't figured that out either without having to go in and change each individual indicator. I'm clearly not a programmer.

Here is the code I have so far and a screen shot.

//Version: 11
//Last Update Date: May 23, 2011
//+------------------------------------------------------------------+
//| XP Moving Average |
//| xpMA.mq4 |
//| Developed by Coders Guru |
//| http://www.xpworx.com |
//+------------------------------------------------------------------+
#property link "http://www.xpworx.com"
//+------------------------------------------------------------------+
#property indicator_chart_window
#property indicator_buffers 4
#property indicator_color1 Yellow
#property indicator_color2 Green
#property indicator_color3 Red
#property indicator_width1 1
#property indicator_width2 1
#property indicator_width3 1
//+------------------------------------------------------------------+
/* Moving average types constants:
------------------------------------
MODE_SMA 0 Simple moving average,
MODE_EMA 1 Exponential moving average,
MODE_SMMA 2 Smoothed moving average,
MODE_LWMA 3 Linear weighted moving average.
MODE_DEMA 4 Double Exponential Moving Average.
MODE_TEMA 5 Triple Exponential Moving Average.
MODE_T3MA 6 T3 Moving Average.
MODE_JMA 7 Jurik Moving Average.
MODE_HMA 8 Hull Moving Average.
MODE_DECEMA 9 DECEMA Moving Average.
MODE_SALT 10 SALT Indicator.
------------------------------------*/
#define MODE_DEMA 4
#define MODE_TEMA 5
#define MODE_T3MA 6
#define MODE_JMA 7
#define MODE_HMA 8
#define MODE_DECEMA 9
#define MODE_SALT 10
/* Applied price constants:
-------------------------------
PRICE_CLOSE 0 Close price.
PRICE_OPEN 1 Open price.
PRICE_HIGH 2 High price.
PRICE_LOW 3 Low price.
PRICE_MEDIAN 4 Median price, (high+low)/2.
PRICE_TYPICAL 5 Typical price, (high+low+close)/3.
PRICE_WEIGHTED 6 Weighted close price, (high+low+close+close)/4.
--------------------------------- */
extern int MA_Period = 25;
extern int MA_Type = MODE_LWMA;
extern int MA_Applied = PRICE_CLOSE;
extern double T3MA_VolumeFactor = 0.8;
extern double JMA_Phase = 1;
extern int Step_Period = 1;
//+------------------------------------------------------------------+
extern int BarsCount = 20000;
extern bool Alert_On = false;
extern bool Arrows_On = false;
extern bool Email_On = false;
//+------------------------------------------------------------------+
int UpArrowCode = 241;
int DownArrowCode = 242;
color UpArrowColor = Red;
color DownArrowColor = Blue;
int UpArrowSize = 3;
int DownArrowSize = 3;
//+------------------------------------------------------------------+
string pro = "xpMA v11";
string ver = "";
//+------------------------------------------------------------------+
double UpBuffer[];
double DownBuffer[];
double buf[];
double buffer[];
double tempbuffer[];
double matriple[];
double signal[];
//+------------------------------------------------------------------+
int nShift;
double point;
//+------------------------------------------------------------------+
int init()
{
ver = GenVer();
DeleteObjects();

Stamp("ver",pro+" - "+ver,15,20);
string copy = "C 2005-2011 XPWORX. All rights reserved.";
copy = StringSetChar(copy,0,'');
Stamp("copyright",copy ,15,35);


IndicatorBuffers(7);

SetIndexStyle(1,DRAW_LINE,STYLE_SOLID,0);
SetIndexBuffer(2,UpBuffer);
SetIndexStyle(1,DRAW_LINE,STYLE_SOLID,0);
SetIndexBuffer(1,DownBuffer);
SetIndexStyle(0,DRAW_LINE,STYLE_SOLID,0);
SetIndexBuffer(0,buf);

SetIndexBuffer(3,signal);
SetIndexBuffer(4,buffer);
SetIndexBuffer(5,tempbuffer);
SetIndexBuffer(6,matriple);

SetIndexLabel(0,"XP Moving Average");
SetIndexLabel(1,"DownBuffer");
SetIndexLabel(2,"UpBuffer");
SetIndexLabel(3,"Signal");

switch(Period())
{
case 1: nShift = 5; break;
case 5: nShift = 7; break;
case 15: nShift = 10; break;
case 30: nShift = 15; break;
case 60: nShift = 20; break;
case 240: nShift = 30; break;
case 1440: nShift = 80; break;
case 10080: nShift = 150; break;
case 43200: nShift = 250; break;
}

if(Digits==2 || Digits==3) point=0.01;
if(Digits==4 || Digits==5) point=0.0001;

return(0);
}

int deinit()
{
DeleteObjects();
return(0);
}

void start()
{
int limit;
int counted_bars=IndicatorCounted();
if(counted_bars<0) return(-1);
if(counted_bars>0) counted_bars--;
limit=Bars-counted_bars;

switch (MA_Type)
{
case MODE_SMA:
case MODE_EMA:
case MODE_SMMA:
case MODE_LWMA:
{
for(int i=0; i<limit; i++) buffer[i] = iMA(NULL,0,MA_Period,0,MA_Type,MA_Applied,i);
break;
}
case MODE_DEMA:
{
for(i=0; i<limit; i++) tempbuffer[i] = iMA(NULL,0,MA_Period,0,MODE_EMA,MA_Applied,i);
for(i=0; i<limit; i++) matriple[i] = iMAOnArray(tempbuffer,0,MA_Period,0,MODE_EMA,i);
for(i=0; i<limit; i++) buffer[i] = iMAOnArray(matriple,0,MA_Period,0,MODE_EMA,i);
break;
}
case MODE_TEMA:
{
for(i=0; i<limit; i++) tempbuffer[i] = iMA(NULL,0,MA_Period,0,MODE_EMA,MA_Applied,i);
for(i=0; i<limit; i++) buffer[i] = iMAOnArray(tempbuffer,0,MA_Period,0,MODE_EMA,i);
break;
}
case MODE_T3MA:
{
for(i=0; i<limit; i++) buffer[i] = iCustom(NULL,0,"T3MA",MA_Period,T3MA_VolumeFactor,0,i);
break;
}
case MODE_JMA:
{
for(i=0; i<limit; i++) buffer[i] = iCustom(NULL,0,"JMA",MA_Period,JMA_Phase,0,i);
break;
}
case MODE_HMA:
{
for(i=0; i<limit; i++) buffer[i] = iCustom(NULL,0,"HMA",MA_Period,0,i);
break;
}
case MODE_DECEMA:
{
for(i=0; i<limit; i++) buffer[i] = iCustom(NULL,0,"DECEMA_v1",MA_Period,MA_Applied,0,i);
break;
}
case MODE_SALT:
{
for(i=0; i<limit; i++) buffer[i] = iCustom(NULL,0,"SATL",0,i);
break;
}
}

if(limit<BarsCount) BarsCount = limit;

for(int shift=0; shift<BarsCount; shift++)
{
UpBuffer[shift] = buffer[shift];
DownBuffer[shift] = buffer[shift];
buf[shift] = buffer[shift];
}

for(shift=0; shift<BarsCount; shift++)
{
double dMA = 0;
for(int k = shift+1; k <= shift+Step_Period; k++) dMA += buffer[k];
dMA = dMA / Step_Period;

if (buffer[shift] < dMA) UpBuffer[shift] = EMPTY_VALUE;
else if (buffer[shift]>dMA) DownBuffer[shift] = EMPTY_VALUE;
else
{
UpBuffer[shift] = EMPTY_VALUE;
DownBuffer[shift] = EMPTY_VALUE;
}
}
for(shift=0; shift<BarsCount-1; shift++)
{
signal[shift]=0;
if(UpBuffer[shift+1] == EMPTY_VALUE && UpBuffer[shift] != EMPTY_VALUE && buf[shift+1] != UpBuffer[shift] )
{
if(Arrows_On && shift !=0) DrawObject(1,shift, buffer[shift] - nShift*point);
if(Arrows_On && shift ==0) DrawOnce(1,shift, buffer[shift] - nShift*point,0);
signal[shift] = 1;
}

if(DownBuffer[shift+1] == EMPTY_VALUE && DownBuffer[shift] != EMPTY_VALUE && buf[shift+1] != DownBuffer[shift])
{
if(Arrows_On && shift !=0) DrawObject(2,shift, buffer[shift] + nShift*point);
if(Arrows_On && shift ==0) DrawOnce(2,shift, buffer[shift] + nShift*point,1);
signal[shift] = -1;
}
}

if(UpBuffer[1] == EMPTY_VALUE && UpBuffer[0] != EMPTY_VALUE && buf[1] != UpBuffer[0])
{
if(Alert_On) AlertOnce(Symbol()+ ":" + PeriodToText() + " - Up Signal",1);
if(Email_On) SendMailOnce("xpMA Signal",Symbol()+ ":" + PeriodToText() + " - Up Signal",1);
}
if(DownBuffer[1] == EMPTY_VALUE && DownBuffer[0] != EMPTY_VALUE && buf[1] != DownBuffer[0])
{
if(Alert_On) AlertOnce(Symbol()+ ":" + PeriodToText() + " - Down Signal",2);
if(Email_On) SendMailOnce("xpMA Signal",Symbol()+ ":" + PeriodToText() + " - Down Signal",2);
}

return(0);
}

bool DrawOnce(int direction, int bar , double price, int ref)
{
static int LastDraw[10];

if( LastDraw[ref] == 0 || LastDraw[ref] < Bars)
{
DrawObject(direction, bar , price);
LastDraw[ref] = Bars;
return (true);
}
return(false);
}

void DrawObject(int direction, int bar , double price)
{
static int count = 0;
count++;
string Obj = "";
if (direction==1) //up arrow
{
Obj = "xpMA_up_" + DoubleToStr(bar,0);
ObjectCreate(Obj,OBJ_ARROW,0,Time[bar],price);
ObjectSet(Obj,OBJPROP_COLOR,UpArrowColor);
ObjectSet(Obj,OBJPROP_ARROWCODE,UpArrowCode);
ObjectSet(Obj,OBJPROP_WIDTH,UpArrowSize);
}
if (direction==2) //down arrow
{
Obj = "xpMA_down_" + DoubleToStr(bar,0);
ObjectCreate(Obj,OBJ_ARROW,0,Time[bar],price);
ObjectSet(Obj,OBJPROP_COLOR,DownArrowColor);
ObjectSet(Obj,OBJPROP_ARROWCODE,DownArrowCode);
ObjectSet(Obj,OBJPROP_WIDTH,DownArrowSize);
}
WindowRedraw();
}

void DeleteObjects()
{
int objs = ObjectsTotal();
string name;
for(int cnt=ObjectsTotal()-1;cnt>=0;cnt--)
{
name=ObjectName(cnt);
if (StringFind(name,"xpMA",0)>-1) ObjectDelete(name);
if (StringFind(name,"Stamp",0)>-1) ObjectDelete(name);
WindowRedraw();
}
}

bool AlertOnce(string msg, int ref)
{
static int LastAlert[10];

if( LastAlert[ref] == 0 || LastAlert[ref] < Bars)
{
Alert(msg);
LastAlert[ref] = Bars;
return (true);
}
return(false);
}

bool SendMailOnce(string subject, string body, int ref)
{
static int LastAlert[10];

if( LastAlert[ref] == 0 || LastAlert[ref] < Bars)
{
SendMail(subject,body);
LastAlert[ref] = Bars;
return (true);
}
return(false);
}

string PeriodToText()
{
switch (Period())
{
case 1:
return("M1");
break;
case 5:
return("M5");
break;
case 15:
return("M15");
break;
case 30:
return("M30");
break;
case 60:
return("H1");
break;
case 240:
return("H4");
break;
case 1440:
return("D1");
break;
case 10080:
return("W1");
break;
case 43200:
return("MN1");
break;
}
}

void Stamp(string objName , string text , int x , int y)
{
string Obj="Stamp_" + objName;
int objs = ObjectsTotal();
string name;

for(int cnt=0;cnt<ObjectsTotal();cnt++)
{
name=ObjectName(cnt);
if (StringFind(name,Obj,0)>-1)
{
ObjectSet(Obj,OBJPROP_XDISTANCE,x);
ObjectSet(Obj,OBJPROP_YDISTANCE,y);
WindowRedraw();
}
else
{
ObjectCreate(Obj,OBJ_LABEL,0,0,0);
ObjectSetText(Obj,text,8,"arial",Orange);
ObjectSet(Obj,OBJPROP_XDISTANCE,x);
ObjectSet(Obj,OBJPROP_YDISTANCE,y);
WindowRedraw();
}
}
if (ObjectsTotal() == 0)
{
ObjectCreate(Obj,OBJ_LABEL,0,0,0);
ObjectSetText(Obj,text,8,"arial",Orange);
ObjectSet(Obj,OBJPROP_XDISTANCE,x);
ObjectSet(Obj,OBJPROP_YDISTANCE,y);
WindowRedraw();

}

return(0);
}


string GenVer()
{
string method;
if(MA_Type==0) method="SMA";
if(MA_Type==1) method="EMA";
if(MA_Type==2) method="SMMA";
if(MA_Type==3) method="LWMA";
if(MA_Type==4) method="DEMA";
if(MA_Type==5) method="TEMA";
if(MA_Type==6) method="T3MA";
if(MA_Type==7) method="JMA";
if(MA_Type==8) method="HMA";
if(MA_Type==9) method="DECEMA";
if(MA_Type==10) method="SALT";

return (method+"("+MA_Period+")");
}

http://i537.photobucket.com/albums/f...artexample.jpg

This is awesome work, but I can't get the code to compile. Do you have MQ4 you can post? Much appreciated.

xronin-
That's why when posting code it should always be put between the CODE tags because it gets mangled when you post it as text.
I have removed all the spaces and it now compiles.

Cool...thanks. I'll take a look.
